用 Jekyll Markdown 写 blog 文档,受到一些限制,通过 JS 扩展了几个简单的语法。
<div class="highlighter-rouge" foldctrl="1"></div>
放到代码前面即可。
<div class="mermaid">
graph TB
subgraph 引擎
Irrlicht(Irrlicht) --> OpenGL[Driver OpenGL]
Irrlicht --> OpenGLES[Driver OpenGL ES]
OpenGL -- "OpenGL" --> Windows[Windows]
OpenGLES -- "OpenGL ES" --> Emulator[OpenGL ES Emulator]
Emulator -- "OpenGL" --> Windows
OpenGLES -- "OpenGL ES" --> Android
OpenGLES -- "OpenGL ES" --> iOS
end
subgraph 特效
Windows -.- OpenGLShader>支持 OpenGL 特效]
Windows -.- OpenGLESShader>支持 OpenGL ES 特效]
Android -.- OpenGLESShader
iOS -.- OpenGLESShader
end
新引擎结构图
classDef orange fill:#f96;
classDef yellow fill:#fefe00;
classDef dotbox fill:#ffc864,stroke:#f668,stroke-width:1px;
classDef titlec fill:#ccc1,stroke:#aaa4,stroke-width:1px,stroke:1;
class Irrlicht orange;
class Windows orange;
class Android orange;
class iOS orange;
class OpenGL yellow;
class OpenGLES yellow;
class 新引擎结构图 titlec;
class OpenGLShader dotbox;
class OpenGLESShader dotbox;
</div>
<div class="mermaid">
graph TB
subgraph 第一组配色
橙色 [橙色<br/>#F93]
淡橙色 [淡橙色<br/>#FFB366]
蓝色 [蓝色<br/>#66B2FF]
淡紫色 [淡紫色<br/>#CCE5FF]
绿色 [绿色<br/>#6F6]
浅蓝色 [浅蓝色<br/>#9FF]
黄色 [黄色<br/>#FF0]
end
DEMO
classDef corange fill:#F93;
classDef corangelt fill:#FFB366;
classDef cblue fill:#66B2FF;
classDef cpurplelt fill:#CCE5FF;
classDef cgreen fill:#6F6;
classDef cbluelt fill:#9FF;
classDef cyellow fill:#FF0;
classDef dotbox fill:#ffc864,stroke:#f668,stroke-width:1px;
classDef titlec fill:#ccc1,stroke:#aaa4,stroke-width:1px,stroke:1;
class 橙色 corange;
class 淡橙色 corangelt;
class 蓝色 cblue;
class 淡紫色 cpurplelt;
class 绿色 cgreen;
class 浅蓝色 cbluelt;
class 黄色 cyellow;
class DEMO titlec;
</div>
<div class="mermaid">
graph TB
subgraph 第二组配色
靛蓝色[靛蓝色<br/>#4273c1]
绿色2[绿色2<br/>#6eaf49]
灰色2[灰色2<br/>#a1a5a6]
蓝色2[蓝色2<br/>#5c9ad1]
黄色2[黄色2<br/>#fbbe04]
橙色2[橙色2<br/>#ea7c2e]
end
DEMO2
classDef indigo fill:#4273c1;
classDef green fill:#6eaf49;
classDef gray fill:#a1a5a6;
classDef blue fill:#5c9ad1;
classDef yellow fill:#fbbe04;
classDef orange fill:#ea7c2e;
classDef dotbox fill:#ffc864,stroke:#f668,stroke-width:1px;
classDef titlec fill:#ccc1,stroke:#aaa4,stroke-width:1px,stroke:1;
class DEMO2 titlec;
class 靛蓝色 indigo;
class 绿色2 green;
class 灰色2 gray;
class 蓝色2 blue;
class 黄色2 yellow;
class 橙色2 orange;
</div>
relocate
属性的节点,向前挪动到最近的一个 ol/ul
列表对应 index 位置。<span imgid="3.3" />
指定位置。function changeImagePositionk() {
var lrelocate = $("#postdiv div[relocate]");
lrelocate = $(lrelocate.get().reverse()); // 倒叙,保证多图的情况能正常。
lrelocate.each(function() {
var imgnode = $(this);
var target = imgnode;
var tname = target[0].tagName.toUpperCase();
while (tname != "OL" && tname != "UL" && target.length) {
target = target.prev();
tname = target[0].tagName.toUpperCase();
}
var relocate = imgnode.attr("relocate");
if (target.length && relocate) {
// <span imgid="3.3" />
var insert = target.find("span[imgid='"+relocate+"']");
if (insert.length) {
imgnode.insertAfter(insert);
return;
}
}
var li = relocate.split("."); // ["2", "3"]
for (var i = 0; i < li.length && target.length; i++) {
// https://www.cnblogs.com/ooo0/p/6278102.html
if (i == 0) {
var children = target.children("li");
target = children.eq(parseInt(li[i]) - 1);
} else {
var children = target.children("ol,ul").children("li");
target = children.eq(parseInt(li[i]) - 1);
}
}
if (target.length) {
imgnode.insertAfter(target);
}
});
}
// 文档加载完成时
$(document).ready(function () {
checkTableStyle();
changeImagePositionk();
});
1. gitee
2. headw
* test <span imgid="headw" />
* test
3. question
{% include image.html url="/assets/images/210402-win-jekyll-ex/gitee.png" relocate="1" caption="1" width="100px" %}
{% include image.html url="/assets/images/210402-win-jekyll-ex/question.jpg" relocate="2.2" caption="2.2" width="100px" %}
{% include image.html url="/assets/images/210402-win-jekyll-ex/headw.png" relocate="headw" caption="headw" width="100px" %}
<table class="tablestyle" ntablew="2:3:5"></table>
Markdown 表格前面加一行,JS 就会根据对应参数调整当前表格的列宽。
function setTableStyle(ithis, ratiostr, tablew) {
if (tablew) {
ithis.css('width', tablew);
}
var li = ratiostr.split(":"); // ["2", "3", "4", "5"]
var total = 0;
for (var i = 0; i < li.length; i++) {
li[i] = parseInt(li[i]);
total += li[i];
}
if (total <= 0) {
return;
}
for (var i = 0; i < li.length; i++) {
li[i] = li[i] / total * 100;
var selector = 'th:nth-of-type(' + (i+1) + '),td:nth-of-type(' + (i+1) + ')';
var width = li[i] + '%';
// th:nth-of-type(n+2) -- 支持表达式 n+2 之类的
// https://www.w3school.com.cn/cssref/css_selectors.asp
ithis.find(selector).each(function() {
$(this).css('width', width);
});
}
}
function checkTableStyle() {
// 先给所有 table 编号。
$("table").each(function() {
var $this = $(this);
if (!$this.attr("tsNumbered")) {
$this.attr("tsNumbered", 1);
var number = $.fn.tsNumber;
$.fn.tsNumber++;
$this.attr("tsNumber", number);
}
});
$("table.tablestyle").each(function() {
var $this = $(this);
var ratiostr = $this.attr("ntablew");
var number = parseInt($this.attr("tsNumber"));
var tablew = $this.attr("tablew");
$this.remove(); // $this.hide();
if (!ratiostr) {
return;
}
$("table").each(function() {
var ithis = $(this);
var inumber = parseInt(ithis.attr("tsNumber"));
// 紧接着的那个 table
if (inumber == number + 1) {
setTableStyle(ithis, ratiostr, tablew);
}
});
});
}
// 文档加载完成时
$(document).ready(function () {
checkTableStyle();
});
<table class="tablestyle" ntablew="2:3:5"></table>
| A | B | C |
| ---- | ---- | ---- |
| 2 | 3 | 5 |
A | B | C |
---|---|---|
2 | 3 | 5 |
